Product Specifications
| Milling Diameter (Inch) | 5/64" |
| Milling Diameter (Decimal Inch) | 0.0780" |
| Number of Flutes | 2 |
| Length Of Cut (Inch) | 1/16" |
| Length Of Cut (Decimal Inch) | 0.0620" |
| Overall Reach (Inch) | 25/32" |
| Overall Reach (Decimal Inch) | 0.7810" |
| Finish/Coating | AlTiN Nano |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Single or Double End | Single |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Center Cutting (Yes/No) | Yes |
| Neck Diameter (Decimal Inch) | 0.0750" |
| LOC Multiple | 0.8x |
| Reach Multiple | 10x |
| Metric (Yes/No) | No |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Mill Diameter (Inch):
5/64"
Mill Diameter (Decimal Inch):
0.0780"
Number of Flutes:
2
Length of Cut (Inch):
1/16"
Length of Cut (Decimal Inch):
0.0620"
Shank Type:
Reduced
Overall Reach (Inch):
25/32"
Overall Reach (Decimal Inch):
0.7810"
Material:
Carbide
Finish/Coating:
AlTiN Nano
Shank Diameter (Inch):
1/4"
Shank Diameter (Decimal Inch):
0.2500"
Application:
Hardened Steels
Single or Double End:
Single
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.5000"
Center Cutting:
Yes
Ships:
From Partner Facility
