| Size | 8 |
| Milling Diameter (Decimal Inch) | 0.1200" |
| Max Depth of Thread (Inch) | 3/4" |
| Max Depth of Thread (Decimal Inch) | 0.7500" |
| Number of Flutes | 4 |
| Finish/Coating | AlTiN Nano |
| Included Angle | 60 Degree |
| Shank Diameter (Inch) | 1/4" |
| Shank Diameter (Decimal Inch) | 0.2500" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.5000" |
| Neck Diameter (Decimal Inch) | 0.0840" |
| Length of Cut (Decimal Inch) | 0.0230" |
| Tip Flat (Decimal Inch) | 0.0028" |
