| Cutter Diameter (Inch) | 3/16" |
| Cutter Diameter (Decimal Inch) | 0.1875" |
| Neck Diameter (Inch) | 3/32" |
| Neck Diameter (Decimal Inch) | 0.0930" |
| Cutter Width (Inch) | 1/16" |
| Cutter Width (Decimal Inch) | 0.0620" |
| Neck Length (Inch) | 9/32" |
| Neck Length (Decimal Inch) | 0.2810" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Radial Depth of Cut (Decimal Inch) | 0.0370" |
| Corner Radius (Inch) | 1/64" |
| Corner Radius (Decimal Inch) | 0.0150" |
| Number of Flutes | 6 |
| Reach Multiple | 1.5x |
| Type | I |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | AlTiN |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
