Product Specifications
| Mill Diameter (Inch) | 1/32" |
| Mill Diameter (Decimal Inch) | 0.0312" |
| Length Of Cut (Inch) | 3/32" |
| Length Of Cut (Decimal Inch) | 0.0930" |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Overall Length (Inch) | 1-1/2" |
| Overall Length (Decimal Inch) | 1.5000" |
| Number of Flutes | 4 |
| Finish/Coating | Amorphous Diamond |
| LOC Multiple | 3x |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | Yes |
| Double or Single End | Single |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Material:
Carbide
Mill Diameter (Inch):
1/32"
Mill Diameter (Decimal Inch):
0.0312"
Mill Diameter (mm):
0.7937mm
Length of Cut (Inch):
3/32"
Length of Cut (Decimal Inch):
0.0937"
Length of Cut (mm):
2.381mm
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.175mm
Overall Length (Inch):
1-1/2"
Overall Length (Decimal Inch):
1.5000"
Overall Length (mm):
38.1mm
Number of Flutes:
4
Finish/Coating:
Amorphous Diamond
Ships:
From Partner Facility
