| Cutter Diameter (Inch) | 5/32" |
| Cutter Diameter (Decimal Inch) | 0.1562" |
| Neck Diameter (Decimal Inch) | 0.0980" |
| Length of Cut (Decimal Inch) | 0.1330" |
| Neck Length (Inch) | 1/4" |
| Neck Length (Decimal Inch) | 0.2500" |
| Overall Reach (Decimal Inch) | 0.3830" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Radius (Inch) | 5/64" |
| Radius (Decimal Inch) | 0.0781" |
| Wrap Angle | 270 Degree |
| Number of Flutes | 4 |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Metric (Yes/No) | No |
| Center Cutting (Yes/No) | No |
| Chip Breaker (Yes/No) | No |
| Finish/Coating | TiB2 |
| Double Ended (Yes/No) | No |
| Weldon Flat (Yes/No) | No |
| Coolant Through (Yes/No) | No |
