| Size | 5 |
| Milling Diameter (Inch) | 3/32" |
| Milling Diameter (Decimal Inch) | 0.0930" |
| Max Depth of Thread (Inch) | 1/2" |
| Max Depth of Thread (Decimal Inch) | 0.5000" |
| Number of Flutes | 4 |
| Finish/Coating | AlTiN Nano |
| Included Angle | 60 Degree |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Neck Diameter (Decimal Inch) | 0.0630" |
| Length of Cut (Decimal Inch) | 0.0190" |
| Tip Flat (Decimal Inch) | 0.0023" |
