Product Specifications
| Milling Diameter (Decimal Inch) | 0.1562" |
| Milling Diameter (Inch) | 5/32" |
| Neck Diameter (Decimal Inch) | 0.0780" |
| Neck Diameter (Inch) | 5/64" |
| Cutter Width (Decimal Inch) | 0.0200" |
| Neck Length (Decimal Inch) | 0.2340" |
| Neck Length (Inch) | 15/64" |
| Overall Length (Decimal Inch) | 2.0000" |
| Overall Length (Inch) | 2" |
| Radial Depth Of Cut (Decimal Inch) | 0.0290" |
| Radius (Decimal Inch) | 0.0100" |
| Number of Flutes | 6 |
| Reach Multiple | 1.5x |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Shank Diameter (Inch) | 3/16" |
| Metric | No |
| Coating | Uncoated |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutting Diameter (Inch):
5/32"
Cutting Diameter (Decimal Inch):
0.1562"
Cutting Width (Decimal Inch):
0.0200"
Tooth Configuration:
Straight
Neck Length (Inch):
15/64"
Neck Length (Decimal Inch):
0.2340"
Material:
Carbide
Finish/Coating:
Uncoated
Shank Diameter (Inch):
3/16"
Shank Diameter (Decimal Inch):
0.1875"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Ships:
From Partner Facility
