Product Specifications
| Milling Diameter (Decimal Inch) | 0.3750" |
| Milling Diameter (Inch) | 3/8" |
| Neck Diameter (Decimal Inch) | 0.1870" |
| Neck Diameter (Inch) | 3/16" |
| Cutter Width (Decimal Inch) | 0.0938" |
| Neck Length (Decimal Inch) | 1.1250" |
| Neck Length (Inch) | 1-1/8" |
| Overall Length (Decimal Inch) | 3.0000" |
| Overall Length (Inch) | 3" |
| Radial Depth Of Cut (Decimal Inch) | 0.0840" |
| Radius (Decimal Inch) | 0.0469" |
| Radius (Inch) | 3/64" |
| Number of Flutes | 6 |
| Reach Multiple | 3x |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Shank Diameter (Inch) | 3/8" |
| Metric | No |
| Coating | Uncoated |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutting Diameter (Inch):
3/8"
Cutting Diameter (Decimal Inch):
0.3750"
Cutting Width (Decimal Inch):
0.0938"
Tooth Configuration:
Straight
Neck Length (Inch):
1-1/8"
Neck Length (Decimal Inch):
1.1250"
Material:
Carbide
Finish/Coating:
Uncoated
Shank Diameter (Inch):
3/8"
Shank Diameter (Decimal Inch):
0.3750"
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Ships:
From Partner Facility
