Features
- 300 Degree spherical ball
- Designed for undercutting, deburring and multi-axis machining
- Center cutting
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | 984040-C3 |
| Cutter Diameter (Inch) | 0.6250" (5/8) |
| Neck Diameter (Inch) | 0.2920" |
| Length of Cut (Inch) | 0.5830" |
| Overall Reach (Inch) | 1.5830" |
| Overall Length (Inch) | 3.5000" (3-1/2) |
| Neck Length (Inch) | 1.0000" (1) |
| Radius (Inch) | 0.3125" (5/16) |
| Shank Diameter (Inch) | 0.6250" (5/8) |
| Wrap Angle | 300 Degree |
| Number of Flutes | 4 |
| Coating | C3 |
| Profile | Spherical |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Harvey Tool
Cutter Diameter (Inch):
5/8"
Cutter Diameter (Decimal Inch):
0.6250"
Neck Diameter (Decimal Inch):
0.2920"
Radius (Inch):
5/16"
Radius (Decimal Inch):
0.3125"
Number of Flutes:
4
Length of Cut (Decimal Inch):
0.5830"
Neck Length (Inch):
1"
Neck Length (Decimal Inch):
1.0000"
Overall Reach (Decimal Inch):
1.5830"
Overall Length (Inch):
3-1/2"
Overall Length (Decimal Inch):
3.5000"
Shank Diameter (Inch):
5/8"
Shank Diameter (Decimal Inch):
0.6250"
Shank Diameter (mm):
15.88mm
Finish/Coating:
C3
interval quantity:
1
