| Neck Diameter (Decimal Inch) | 0.0470" |
| Neck Diameter (Inch) | 3/64" |
| Length Of Cut (Decimal Inch) | 0.0240" |
| Overall Reach (Decimal Inch) | 0.3750" |
| Overall Reach (Inch) | 3/8" |
| Overall Length (Decimal Inch) | 2.5000" |
| Overall Length (Inch) | 2-1/2" |
| Tip Diameter (Decimal Inch) | 0.0050" |
| Angle Per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 2 |
| Reach Multiple | 8x |
| Type | I |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/8" |
| Metric | No |
| Coating | AlTiN |
| Single or Double Angle | Single |
