Product Specifications
| Manufacturer Part Number | 31752W |
| Cutter Diameter (Decimal Inch) | 1.000" |
| Cutter Diameter (Inch) | 1" |
| Length of Cut (Decimal Inch) | 4.250" |
| Length of Cut (Inch) | 4-1/4" |
| Overall Length (Decimal Inch) | 7.000" |
| Overall Length (Inch) | 7" |
| Corner Radius (Decimal Inch) | 0.030" |
| Number of Flutes | 4 |
| Shank Diameter (Decimal Inch) | 1.000" |
| Shank Diameter (Inch) | 1" |
| Coating | APLUS |
| Center Cutting | Yes |
| Weldon Flat | Yes |
| Product Type | Corner Radius End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Helical Solutions
Cutter Diameter (Inch):
1"
Cutter Diameter (Decimal Inch):
1.0000"
Cutter Diameter (mm):
25.40mm
Length of Cut (Inch):
4-1/4"
Length of Cut (Decimal Inch):
4.2500"
Length of Cut (mm):
107.95mm
Overall Length (Inch):
7"
Overall Length (Decimal Inch):
7.0000"
Overall Length (mm):
177.80mm
Corner Radius (Inch):
2/67"
Corner Radius (Decimal Inch):
0.0300"
Corner Radius (mm):
0.76mm
Shank Diameter (Inch):
1"
Shank Diameter (Decimal Inch):
1.0000"
Shank Diameter (mm):
25.40mm
Number of Flutes:
4
Finish/Coating:
APLUS Coated
