Product Specifications
| # Manufacturer Number | 88486 |
| Cutter Diameter (Inch) | 5/16" |
| Cutter Diameter (Decimal Inch) | 0.3125" |
| Pilot Diameter (Inch) | 9/64" |
| Pilot Diameter (Decimal Inch) | 0.1460" |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.0000" |
| Length of Cut (Inch) | 5/64" |
| Length of Cut (Decimal Inch) | 0.0832" |
| Corner Radius (Inch) | 5/64" |
| Corner Radius (Decimal Inch) | 0.0780" |
| Radius (Inch) | 5/64" |
| Radius (Decimal Inch) | 0.0780" |
| Number of Flutes | 5 |
| Pilot Flare | 2 |
| Shoulder Flare | 2 |
| Center Cutting (Yes/No) | No |
| Coating | Zplus |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Helical Solutions
Cutter Diameter (Inch):
5/16"
Cutter Diameter (Decimal Inch):
0.3125"
Pilot Diameter (Decimal Inch):
0.1460"
Length of Cut (Decimal Inch):
0.0832"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Corner Radius (Inch):
5/64"
Corner Radius (Decimal Inch):
0.0780"
Radius (Inch):
5/64"
Radius (Decimal Inch):
0.0780"
Number of Flutes:
5
Shank Diameter (Inch):
5/16"
Shank Diameter (Decimal Inch):
0.3125"
Shank Length (Decimal Inch):
1.9168"
Finish/Coating:
ZPLUS
Center Cutting:
No
Through Coolant:
No
interval quantity:
1
