Product Specifications
| Manufacturer Part Number | 89256 |
| Cutter Diameter (Decimal Inch) | 0.125" |
| Cutter Diameter (Inch) | 1/8" |
| Neck Diameter (Decimal Inch) | 0.1180" |
| Length of Cut (Decimal Inch) | 0.156" |
| Length of Cut (Inch) | 5/32" |
| Overall Reach (Decimal Inch) | 0.375" |
| Overall Reach (Inch) | 3/8" |
| Overall Length (Decimal Inch) | 2.000" |
| Overall Length (Inch) | 2" |
| Neck Diameter (mm) | 3.00mm |
| Corner Radius (Decimal Inch) | 0.010" |
| Number of Flutes | 5 |
| LOC Multiple | 1.3x |
| Shank Diameter (Decimal Inch) | 0.125" |
| Shank Diameter (Inch) | 1/8" |
| Coating | TPLUS |
| Center Cutting | Yes |
| Chip Breaker | Yes |
| Product Type | Corner Radius End Mill |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Helical Solutions
Cutter Diameter (Inch):
1/8"
Cutter Diameter (Decimal Inch):
0.1250"
Cutter Diameter (mm):
3.18mm
Length of Cut (Inch):
5/32"
Length of Cut (Decimal Inch):
0.1560"
Length of Cut (mm):
3.96mm
Overall Reach (Inch):
3/8"
Overall Reach (Decimal Inch):
0.3750"
Overall Reach (mm):
9.53mm
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.0000"
Overall Length (mm):
50.80mm
Corner Radius (Inch):
1/64"
Corner Radius (Decimal Inch):
0.0100"
Corner Radius (mm):
0.25mm
Shank Diameter (Inch):
1/8"
Shank Diameter (Decimal Inch):
0.1250"
Shank Diameter (mm):
3.18mm
Number of Flutes:
5
Finish/Coating:
TPLUS Coated
