Product Specifications
| Mount Type | Tapered |
| Maximum Drill Chuck Capacity (Inch) | 33/64" |
| Maximum Drill Chuck Capacity (Decimal Inch) | 0.5120" |
| Maximum Drill Chuck Capacity (mm) | 13mm |
| Minimum Drill Chuck Capacity (Inch) | 1/32" |
| Minimum Drill Chuck Capacity (Decimal Inch) | 0.0390" |
| Minimum Drill Chuck Capacity (mm) | 1mm |
| Key Style | Keyless |
| Bearing Type | Ball Bearing |
| Taper Size | 2JT |
| Closed Length (Inch) | 3-29/32" |
| Closed Length (Decimal Inch) | 3.9000" |
| Closed Length (mm) | 99.06mm |
| Open Length (Inch) | 3-29/64" |
| Open Length (Decimal Inch) | 3.4600" |
| Open Length (mm) | 87.88mm |
| Sleeve Diameter (Inch) | 1-13/16" |
| Sleeve Diameter (Decimal Inch) | 1.8100" |
| Sleeve Diameter (mm) | 45.97mm |
| Total Indicator Reading | 0.0016" |
| Material | Steel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Jacobs
Mount Type:
Tapered
Maximum Drill Chuck Capacity (Inch):
33/64"
Maximum Drill Chuck Capacity (Decimal Inch):
0.5120"
Maximum Drill Chuck Capacity (mm):
13mm
Minimum Drill Chuck Capacity (Inch):
1/32"
Minimum Drill Chuck Capacity (Decimal Inch):
0.0390"
Minimum Drill Chuck Capacity (mm):
1mm
Key Style:
Keyless
Bearing Type:
Ball Bearing
Taper Size:
2JT
Closed Length (Inch):
3-29/32"
Closed Length (Decimal Inch):
3.9000"
Closed Length (mm):
99.06mm
Open Length (Inch):
3-29/64"
Open Length (Decimal Inch):
3.4600"
Open Length (mm):
87.88mm
Sleeve Diameter (Inch):
1-13/16"
Sleeve Diameter (Decimal Inch):
1.8100"
Sleeve Diameter (mm):
45.97mm
Total Indicator Reading:
0.0016"
Material:
Steel
Ships:
From Partner Facility
IsDiscontinued:
