| Manufacturer Part Number | 934-000-301 |
| Cutting Diameter (Decimal Inch) | 0.138" |
| Connection Diameter (Decimal Inch) | 0.188" |
| Overall Length (Decimal Inch) | 1.500" |
| Functional Length (Decimal Inch) | 0.418" |
| Length of Shank (Decimal Inch) | 0.952" |
| Cutting Edge Corner Radius (Decimal Inch) | 0.069" |
| Cutting Edge Count | 2 |
| Included Angle (Degree) | 82 Degree |
| Maximum Axial Depth of Cut (Decimal Inch) | 0.413" |
| Connection Type | Shank |
| Cutting Direction | Right Hand |
| Material | HSS |
| Product Type | Ball End Mill |
