Features:
| Tool Number | 8800821 |
| Max Depth of Cut (Decimal Inch) | 0.7480" |
| Max Depth of Cut (mm) | 19.00mm |
| Cutting Width (Decimal Inch) | 0.1252" |
| Cutting Width (mm) | 3.18mm |
| Cutting Width Minimum (Decimal Inch) | 0.1252" |
| Cutting Width Minimum (mm) | 3.18mm |
| Cutting Width Maximum (Decimal Inch) | 0.1252" |
| Cutting Width Maximum (mm) | 3.18mm |
| Insert Length (Decimal Inch) | 1.1252" |
| Insert Length (mm) | 28.58mm |
| Corner Radius (Inch) | 0.015" |
| Corner Radius (mm) | 0.38mm |
| Thickness (Inch) | 1/4" |
| Thickness (mm) | 6.35mm |
| Application | External Grooving |
| Coating Process | Uncoated |
| Cutting Range | Finishing |
| Hand | Right Hand |
| Insert Holding Method | Clamp |
| Insert Grade | A65 |
| Insert Size | 125 |
| Material | Ceramic |
| Number of Cutting Edges | 2 |
| Primary Workpiece Material | Cast Iron (K) |
| Usage Classification | Continuous |
