Features:
| Tool Number | 8850672 |
| Max Depth of Cut (Decimal Inch) | 0.2500" |
| Max Depth of Cut (mm) | 6.35mm |
| Cutting Width (Decimal Inch) | 0.2500" |
| Cutting Width (mm) | 6.35mm |
| Cutting Width Minimum (Decimal Inch) | 0.2500" |
| Cutting Width Minimum (mm) | 6.35mm |
| Cutting Width Maximum (Decimal Inch) | 0.2500" |
| Cutting Width Maximum (mm) | 6.35mm |
| Insert Length (Decimal Inch) | 1.2717" |
| Insert Length (mm) | 32.30mm |
| Corner Radius (Inch) | 0.018" |
| Corner Radius (mm) | 0.45mm |
| Thickness (Inch) | 0.453" |
| Thickness (mm) | 11.50mm |
| Application | External Grooving | Internal Large Diameter Shallow Grooving |
| Coating Process | PVD |
| Cutting Range | Finishing |
| Hand | Left Hand |
| Insert Holding Method | Clamp |
| Insert Grade | PR1215 |
| Insert Size | 4250 |
| Material | Carbide |
| Number of Cutting Edges | 2 |
| Primary Workpiece Material | Steel (P) |
| Usage Classification | Continuous |
