Features:
| EDP Number | OTM86120 |
| Maximum Depth of Cut (Decimal Inch) | 0.5770" |
| Maximum Depth of Cut (mm) | 7.11mm |
| Cutting Width (Decimal Inch) | 0.1032" |
| Cutting Width (mm) | 2.62mm |
| Cutting Width Minimum (Decimal Inch) | 0.1032" |
| Cutting Width Minimum (mm) | 2.62mm |
| Cutting Width Maximum (Decimal Inch) | 0.1032" |
| Cutting Width Maximum (mm) | 2.62mm |
| Cutting Diameter (Decimal Inch) | 1.2059 - 1.2059" |
| Cutting Diameter (mm) | 30.63 - 30.63mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.2059" |
| Cutting Diameter Maximum (mm) | 30.63mm |
| Connection Diameter (Decimal Inch) | 0.7500" |
| Connection Diameter (mm) | 19.05mm |
| Tool Entering Angle ( Degree) | 10 Degree |
| Application | Chamfering | Countersinking | Facing |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 2 |
| Number of Inserts | 2 |
| Shank Type | Standard Length |
