Features:
| EDP Number | OTM86128 |
| Maximum Depth of Cut (Decimal Inch) | 0.4720" |
| Maximum Depth of Cut (mm) | 14.88mm |
| Cutting Width (Decimal Inch) | 0.3429" |
| Cutting Width (mm) | 8.71mm |
| Cutting Width Minimum (Decimal Inch) | 0.3429" |
| Cutting Width Minimum (mm) | 8.71mm |
| Cutting Width Maximum (Decimal Inch) | 0.3429" |
| Cutting Width Maximum (mm) | 8.71mm |
| Cutting Diameter (Decimal Inch) | 1.6858 - 1.6858" |
| Cutting Diameter (mm) | 42.82 - 42.82mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.6858" |
| Cutting Diameter Maximum (mm) | 42.82mm |
| Connection Diameter (Decimal Inch) | 0.7500" |
| Connection Diameter (mm) | 19.05mm |
| Tool Entering Angle ( Degree) | 35 Degree |
| Application | Chamfering | Countersinking | Facing |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 2 |
| Number of Inserts | 2 |
| Shank Type | Standard Length |
