Features:
| EDP Number | OTM86415 |
| Maximum Depth of Cut (Decimal Inch) | 0.6000" |
| Maximum Depth of Cut (mm) | 15.24mm |
| Cutting Diameter (Decimal Inch) | 1.5000" |
| Cutting Diameter (mm) | 38.10mm |
| Cutting Diameter Minimum (Decimal Inch) | 1.5000" |
| Cutting Diameter Minimum (mm) | 38.10mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.5000" |
| Cutting Diameter Maximum (mm) | 38.10mm |
| Connection Diameter (Decimal Inch) | 1.0000" |
| Connection Diameter (mm) | 25.40mm |
| Tool Entering Angle ( Degree) | 90 Degree |
| Application | Facing | Ramping | Shouldering | Slotting |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 3 |
| Number of Inserts | 3 |
| Shank Type | Standard Length |
