Kyocera Precision Tools TBZ07012 | WBGW151505T00315LSE KBN25M 3/16" Circle Diameter x 3/32" Thickness PVD Coated CBN Indexable Turning Insert

$33.26
Brand:
Kyocera Precision Tools
Insert Style:
WBGW
Insert Size:
151505
Material:
CBN;Inscribed Circle (Inch)=3/16"""
Inscribed Circle (Decimal Inch):
0.1874"
Inscribed Circle (mm):
4.76mm
Thickness (Inch):
3/32"
Thickness (Decimal Inch):
0.0937"
Thickness (mm):
2.38mm
Corner Radius (Decimal Inch):
0.0080"
Corner Radius (mm):
0.20mm
Manufacturer's Grade:
KBN25M
SKU:
23225769
Weight:
0.02 LBS
Minimum Purchase:
1 unit
Shipping:
Calculated at Checkout

Features:

  • Insert for boring, internal facing
  • Small edge with 1 cutting edge
  • Heat-resistant MEGACOAT on micro-grain CBN with heat resistant binder phase
  • Application: Stable cutting of hardened steel at high speed

Product Specifications
EDP NumberTBZ07012
Inscribed Circle (Inch)3/16"
Inscribed Circle (mm)4.76mm
Corner Radius (Inch)0.008"
Corner Radius (mm)0.20mm
Thickness (Inch)3/32"
Thickness (mm)2.38mm
ApplicationBoring | Internal Facing
Coating ProcessPVD
Cutting RangeMedium
HandLeft Hand
Insert GradeKBN25M
Insert Holding MethodScrew or Clamp
Insert Shape80 Degree Trigon
Insert Included Angle ( Degree)80 Degree
Insert Size151505
MaterialCBN
Number of Cutting Edges1
Primary Workpiece MaterialHardened Materials (H)
Usage ClassificationLight Interruption
