Features:
| EDP Number | TCV05312 |
| Inscribed Circle (Inch) | 1/2" |
| Inscribed Circle (mm) | 12.70mm |
| Corner Radius (Inch) | 3/64" |
| Corner Radius (mm) | 1.20mm |
| Thickness (Inch) | 5/16" |
| Thickness (mm) | 7.94mm |
| Application | Boring | Chamfering | External Turning | Facing |
| Coating Process | PVD |
| Cutting Range | Finishing Medium |
| Hand | Neutral |
| Insert Grade | PT600M |
| Insert Holding Method | Clamp |
| Insert Shape | 90 Degree Square |
| Insert Included Angle ( Degree) | 90 Degree |
| Insert Size | 453 |
| Material | Ceramic |
| Number of Cutting Edges | 8 |
| Primary Workpiece Material | Hardened Materials (H) |
| Usage Classification | Continuous |
