Features:
| EDP Number | THC07177 |
| Shank Width (Decimal Inch) | 0.3937" |
| Shank Width (mm) | 16.00mm |
| Cutting Width (Decimal Inch) | 0.2756" |
| Cutting Width (mm) | 7.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.2756" |
| Cutting Width Minimum (mm) | 7.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.2756" |
| Cutting Width Maximum (mm) | 7.00mm |
| Shank Height (Decimal Inch) | 0.6299" |
| Shank Height (mm) | 16.00mm |
| Tool Entering Angle ( Degree) | 40 Degree |
| Application | Back Turning | Small Parts Machining |
| Hand | Right Hand |
| Insert Holding Method | Anchor Pin |
| Insert Shape | Irregular |
| Material | Steel |
| Rake | Positive |
