Features:
| EDP Number | THC14761 |
| Max Depth of Cut (Decimal Inch) | 0.2165" |
| Max Depth of Cut (mm) | 5.50mm |
| Cutting Width (Decimal Inch) | 0.0311 - 0.1969" |
| Cutting Width (mm) | 0.79 - 5.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.0311" |
| Cutting Width Minimum (mm) | 0.79mm |
| Cutting Width Maximum (Decimal Inch) | 0.1969" |
| Cutting Width Maximum (mm) | 5.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.5748" |
| Contact Surface Diameter Machine Side (mm) | 40.00mm |
| Application | External Shallow Grooving |
| Coolant Through (Yes/No) | Yes |
| Grooving Type | External Grooving |
| Hand | Right Hand |
| Insert Holding Method | Top Clamp |
| Material | Steel |
