Features:
| EDP Number | THD11832 |
| Cutting Diameter (Decimal Inch) | 1.1882" |
| Cutting Diameter (mm) | 30.18mm |
| Cutting Diameter Minimum (Decimal Inch) | 1.1882" |
| Cutting Diameter Minimum (mm) | 30.18mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.1882" |
| Cutting Diameter Maximum (mm) | 30.18mm |
| Connection Diameter (Decimal Inch) | 1.2500" |
| Connection Diameter (mm) | 31.75mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.6142" |
| Contact Surface Diameter Machine Side (mm) | 41.00mm |
| Usable Length (Decimal Inch) | 4.7500" |
| Usable Length (mm) | 120.65mm |
| Application | Drilling |
| Coolant Through (Yes/No) | Yes |
| Drill Depth by Diameter Ratio | 4xD |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 2 |
| Number of Inserts | 2 |
| Shank Type | Standard Length |
| Weldon Flat | Yes |
