Features:
| EDP Number | THD89024 |
| Cutting Diameter (Decimal Inch) | 1.9382" |
| Cutting Diameter (mm) | 49.23mm |
| Cutting Diameter Minimum (Decimal Inch) | 1.9382" |
| Cutting Diameter Minimum (mm) | 49.23mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.9382" |
| Cutting Diameter Maximum (mm) | 49.23mm |
| Connection Diameter (Decimal Inch) | 1.5000" |
| Connection Diameter (mm) | 38.10mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 2.3598" |
| Contact Surface Diameter Machine Side (mm) | 59.94mm |
| Tool Entering Angle ( Degree) | 3.7795 Degree |
| Usable Length (Decimal Inch) | 9.6902" |
| Usable Length (mm) | 246.13mm |
| Application | Drilling |
| Coolant Through (Yes/No) | Yes |
| Drill Depth by Diameter Ratio | 5xD |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 2 |
| Number of Inserts | 2 |
| Shank Type | Standard Length |
| Weldon Flat | Yes |
