Features:
| EDP Number | THD89118 |
| Cutting Diameter (Decimal Inch) | 0.9382" |
| Cutting Diameter (mm) | 23.83mm |
| Cutting Diameter Minimum (Decimal Inch) | 0.9382" |
| Cutting Diameter Minimum (mm) | 23.83mm |
| Cutting Diameter Maximum (Decimal Inch) | 0.9382" |
| Cutting Diameter Maximum (mm) | 23.83mm |
| Connection Diameter (Decimal Inch) | 1.0000" |
| Connection Diameter (mm) | 25.40mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.3799" |
| Contact Surface Diameter Machine Side (mm) | 35.05mm |
| Tool Entering Angle ( Degree) | 5.0394 Degree |
| Usable Length (Decimal Inch) | 3.7500" |
| Usable Length (mm) | 95.25mm |
| Application | Drilling |
| Coolant Through (Yes/No) | Yes |
| Drill Depth by Diameter Ratio | 4xD |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 2 |
| Number of Inserts | 2 |
| Shank Type | Standard Length |
| Weldon Flat | Yes |
