Features:
| EDP Number | THN01157 |
| Maximum Depth of Cut (Decimal Inch) | 0.9252" |
| Cutting Diameter (Decimal Inch) | 4.0000" |
| Cutting Diameter (mm) | 101.60mm |
| Cutting Diameter Minimum (Decimal Inch) | 4.0000" |
| Cutting Diameter Minimum (mm) | 101.60mm |
| Cutting Diameter Maximum (Decimal Inch) | 4.0000" |
| Cutting Diameter Maximum (mm) | 101.60mm |
| Cutting Diameter Maximum (mm) | 1.5000" |
| Connection Bore Diameter (mm) | 38.10mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 2.7500" |
| Contact Surface Diameter Machine Side (mm) | 69.85mm |
| Tool Entering Angle ( Degree) | 1.7721 Degree |
| Application | Facing, Heavy Milling, Shouldering, Slotting |
| Cutter Pitch | Standard Pitch |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 6 |
| Number of Inserts | 6 |
