Features:
| EDP Number | THN03225 |
| Maximum Depth of Cut (Decimal Inch) | 0.3937" |
| Cutting Diameter (Decimal Inch) | 1.9685" |
| Cutting Diameter (mm) | 50.00mm |
| Cutting Diameter Minimum (Decimal Inch) | 1.9685" |
| Cutting Diameter Minimum (mm) | 50.00mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.9685" |
| Cutting Diameter Maximum (mm) | 50.00mm |
| Connection Diameter (Decimal Inch) | 1.2598" |
| Connection Diameter (mm) | 32.00mm |
| Tool Entering Angle ( Degree) | 2.9532 Degree |
| Application | Facing | Shouldering | Slotting |
| Coolant Through (Yes/No) | Yes |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 5 |
| Number of Inserts | 5 |
| Shank Type | Standard Length |
