Features:
| EDP Number | THN08239 |
| Maximum Depth of Cut (Decimal Inch) | 0.0394" |
| Maximum Depth of Cut (mm) | 10.00mm |
| Cutting Diameter (Decimal Inch) | 1.6850 - 2.0000" |
| Cutting Diameter (mm) | 42.80 - 50.80mm |
| Cutting Diameter Minimum (Decimal Inch) | 1.6850" |
| Cutting Diameter Minimum (mm) | 42.80mm |
| Cutting Diameter Maximum (Decimal Inch) | 2.0000" |
| Cutting Diameter Maximum (mm) | 50.80mm |
| Cutting Diameter Maximum (mm) | 0.7500" |
| Connection Bore Diameter (mm) | 19.05mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.7500" |
| Contact Surface Diameter Machine Side (mm) | 44.45mm |
| Tool Entering Angle ( Degree) | 10 Degree |
| Application | Facing | Helical Milling | Plunging | Ramping | Shouldering | Slotting |
| Coolant Through (Yes/No) | Yes |
| Cutter Pitch | Standard Pitch |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 8 |
| Number of Inserts | 8 |
