Features:
| EDP Number | THN08323 |
| Maximum Depth of Cut (Decimal Inch) | 0.0197" |
| Maximum Depth of Cut (mm) | 10.00mm |
| Cutting Diameter (Decimal Inch) | 0.3228 - 0.4724" |
| Cutting Diameter (mm) | 8.20 - 12.00mm |
| Cutting Diameter Minimum (Decimal Inch) | 0.3228" |
| Cutting Diameter Minimum (mm) | 8.20mm |
| Cutting Diameter Maximum (Decimal Inch) | 0.4724" |
| Cutting Diameter Maximum (mm) | 12.00mm |
| Connection Diameter (Decimal Inch) | 0.2559" |
| Connection Diameter (mm) | 6.50mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 0.4410" |
| Contact Surface Diameter Machine Side (mm) | 11.20mm |
| Shank Height (Decimal Inch) | 0.2756" |
| Shank Height (mm) | 7.00mm |
| Application | Facing | Helical Milling | High Feed | Plunging | Ramping | Shouldering | Slotting |
| Coolant Through (Yes/No) | Yes |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 3 |
| Number of Inserts | 3 |
| Shank Type | Modular Connection |
