Features:
| EDP Number | THN08346 |
| Maximum Depth of Cut (Decimal Inch) | 0.0197" |
| Maximum Depth of Cut (mm) | 10.00mm |
| Cutting Diameter (Decimal Inch) | 0.4752 - 0.6252" |
| Cutting Diameter (mm) | 12.07 - 15.88mm |
| Cutting Diameter Minimum (Decimal Inch) | 0.4752" |
| Cutting Diameter Minimum (mm) | 12.07mm |
| Cutting Diameter Maximum (Decimal Inch) | 0.6252" |
| Cutting Diameter Maximum (mm) | 15.88mm |
| Connection Diameter (Decimal Inch) | 0.3347" |
| Connection Diameter (mm) | 8.50mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 0.5787" |
| Contact Surface Diameter Machine Side (mm) | 14.70mm |
| Shank Height (Decimal Inch) | 0.4724" |
| Shank Height (mm) | 12.00mm |
| Application | Facing | Helical Milling | High Feed | Plunging | Ramping | Shouldering | Slotting |
| Coolant Through (Yes/No) | Yes |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 4 |
| Number of Inserts | 4 |
| Shank Type | Modular Connection |
