Features:
| EDP Number | THN08501 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362" |
| Maximum Depth of Cut (mm) | 53.00mm |
| Cutting Diameter (Decimal Inch) | 1.5748" |
| Cutting Diameter (mm) | 40.00mm |
| Cutting Diameter Minimum (Decimal Inch) | 1.5748" |
| Cutting Diameter Minimum (mm) | 40.00mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.5748" |
| Cutting Diameter Maximum (mm) | 40.00mm |
| Cutting Diameter Maximum (mm) | 0.6299" |
| Connection Bore Diameter (mm) | 16.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.4961" |
| Contact Surface Diameter Machine Side (mm) | 38.00mm |
| Tool Entering Angle ( Degree) | 90 Degree |
| Application | Facing, Helical Milling, Plunging, Pocketing, Ramping, Shouldering, Slotting |
| Coolant Through (Yes/No) | Yes |
| Cutter Pitch | Standard Pitch |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 5 |
| Number of Inserts | 5 |
