Features:
| EDP Number | THN08551 |
| Maximum Depth of Cut (Decimal Inch) | 0.2362" |
| Maximum Depth of Cut (mm) | 6mm |
| Cutting Diameter (Decimal Inch) | 0.7500" |
| Cutting Diameter (mm) | 19.05mm |
| Cutting Diameter Minimum (Decimal Inch) | 0.7500" |
| Cutting Diameter Minimum (mm) | 19.05mm |
| Cutting Diameter Maximum (Decimal Inch) | 0.7500" |
| Cutting Diameter Maximum (mm) | 19.05mm |
| Connection Diameter (Decimal Inch) | 0.6252" |
| Connection Diameter (mm) | 15.88mm |
| Tool Entering Angle ( Degree) | 90 Degree |
| Application | Facing | Helical Milling | Plunging | Pocketing | Ramping | Shouldering | Slotting |
| Coolant Through (Yes/No) | Yes |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 2 |
| Number of Inserts | 2 |
| Shank Type | Standard Length |
| Weldon Flat | Yes |
