Features:
| EDP Number | THN08621 |
| Maximum Depth of Cut (Decimal Inch) | 0.0984" |
| Maximum Depth of Cut (mm) | 8.00mm |
| Cutting Diameter (Decimal Inch) | 1.1417 - 1.5748" |
| Cutting Diameter (mm) | 29.00 - 40.00mm |
| Cutting Diameter Minimum (Decimal Inch) | 1.1417" |
| Cutting Diameter Minimum (mm) | 29.00mm |
| Cutting Diameter Maximum (Decimal Inch) | 1.5748" |
| Cutting Diameter Maximum (mm) | 40.00mm |
| Connection Diameter (Decimal Inch) | 1.2598" |
| Connection Diameter (mm) | 32.00mm |
| Tool Entering Angle ( Degree) | 90 Degree |
| Application | Helical Milling | High Feed | Ramping | Shouldering | Slotting |
| Coolant Through (Yes/No) | Yes |
| Hand | Right Hand |
| Insert Holding Method | Screw |
| Material | Steel |
| Number of Flutes | 5 |
| Number of Inserts | 5 |
| Shank Type | Standard Length |
| Weldon Flat | Yes |
