Features:
| EDP Number | THP06836 |
| Maximum Depth of Cut (mm) | 4.00mm |
| Shank Width (mm) | 25.00mm |
| Maximum Cut-Off Diameter (Decimal Inch) | 2.0866" |
| Maximum Cut-Off Diameter (mm) | 53.00mm |
| Cutting Width (Decimal Inch) | 0.1181" |
| Cutting Width (mm) | 3.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.1181" |
| Cutting Width Minimum (mm) | 3.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.1181" |
| Cutting Width Maximum (mm) | 3.00mm |
| Shank Height (Decimal Inch) | 0.9843" |
| Shank Height (mm) | 25.00mm |
| Application | Cut-Off |
| Coolant Through (Yes/No) | Yes |
| Hand | Left Hand |
| Insert Holding Method | Self-Clamp |
| Material | Steel |
