Features:
- Polygon taper design and dual contact between the taper and the flange face for high rigidity
- High precision with locational accuracy +/-2mm
- Distributes cutting forces evenly between 3 faces for enhanced rigidity and center accuracy
- Compatible with GDM, GDG inserts
Product Specifications
| EDP Number | THT05446 |
| Maximum Depth of Cut (mm) | 2.50mm |
| Max Depth of Cut (Decimal Inch) | 0.3937" |
| Max Depth of Cut (mm) | 10.00mm |
| Cutting Width (Decimal Inch) | 0.1181 - 0.1575" |
| Cutting Width (mm) | 3.00 - 4.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.1181" |
| Cutting Width Minimum (mm) | 3.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.1575" |
| Cutting Width Maximum (mm) | 4.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.9685" |
| Contact Surface Diameter Machine Side (mm) | 50.00mm |
| Application | Cut-Off | External Grooving |
| Coolant Through (Yes/No) | Yes |
| Grooving Type | External Grooving |
| Hand | Right Hand |
| Insert Holding Method | Top Clamp |
| Material | Steel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Toolholder Type:
External Grooving
Hand of Holder:
Right-Hand
Maximum Depth of Cut (Decimal Inch):
0.3937"
Maximum Depth of Cut (mm):
10.00mm
Minimum Groove Width (Decimal Inch):
0.1181"
Minimum Groove Width (mm):
3.00mm
Maximum Groove Width (Decimal Inch):
0.1575"
Maximum Groove Width (mm):
4.00mm
Toolholder Style:
KPC
Series:
KPC;Through Coolant=Yes"
