Features:
- Polygon taper design and dual contact between the taper and the flange face for high rigidity
- High precision with locational accuracy +/-2mm
- Distributes cutting forces evenly between 3 faces for enhanced rigidity and center accuracy
- Compatible with GDM, GDG inserts
Product Specifications
| EDP Number | THT05470 |
| Maximum Depth of Cut (mm) | 8.64mm |
| Max Depth of Cut (Decimal Inch) | 0.7874" |
| Max Depth of Cut (mm) | 20.00mm |
| Cutting Width (Decimal Inch) | 0.1575 - 0.1969" |
| Cutting Width (mm) | 4.00 - 5.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.1575" |
| Cutting Width Minimum (mm) | 4.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.1969" |
| Cutting Width Maximum (mm) | 5.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.5748" |
| Contact Surface Diameter Machine Side (mm) | 40.00mm |
| Application | Cut-Off | External Grooving |
| Coolant Through (Yes/No) | Yes |
| Grooving Type | External Grooving |
| Hand | Right Hand |
| Insert Holding Method | Top Clamp |
| Material | Steel |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Toolholder Type:
External Grooving
Hand of Holder:
Right-Hand
Maximum Depth of Cut (Decimal Inch):
0.7874"
Maximum Depth of Cut (mm):
20.00mm
Minimum Groove Width (Decimal Inch):
0.1575"
Minimum Groove Width (mm):
4.00mm
Maximum Groove Width (Decimal Inch):
0.1969"
Maximum Groove Width (mm):
5.00mm
Toolholder Style:
KPC
Series:
KPC;Through Coolant=Yes"
