Features:
| EDP Number | TKB03413 |
| Shank Width (Decimal Inch) | 0.3937" |
| Max Depth of Cut (Decimal Inch) | 0.0591" |
| Max Depth of Cut (mm) | 1.50mm |
| Cutting Width (Decimal Inch) | 0.0787" |
| Cutting Width (mm) | 2.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.0787" |
| Cutting Width Minimum (mm) | 2.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.0787" |
| Cutting Width Maximum (mm) | 2.00mm |
| Connection Diameter (Decimal Inch) | 0.1969" |
| Connection Diameter (mm) | 5.00mm |
| Minimum Bore Diameter (Decimal Inch) | 0.1969" |
| Minimum Bore Diameter (mm) | 5.00mm |
| Shank Height (Decimal Inch) | 0.1693" |
| Shank Height (mm) | 4.30mm |
| Tool Entering Angle ( Degree) | 92 Degree |
| Usable Length (Decimal Inch) | 0.7874" |
| Usable Length (mm) | 20.00mm |
| Corner Radius (Decimal Inch) | 0.002" |
| Corner Radius (mm) | 0.05mm |
| Application | Micro Internal Grooving |
| Coating Process | PVD |
| Grooving Type | Internal Face Grooving |
| Hand | Right Hand |
| Insert Grade | PR1225 |
| Insert Holding Method | Screw |
| Material | Carbide |
| Primary Workpiece Material | Stainless Steel (M) |
