Features:
| EDP Number | TKT09560 |
| Shank Width (Decimal Inch) | 0.6299" |
| Minimum Bore Diameter (Decimal Inch) | 0.0394" |
| Minimum Bore Diameter (mm) | 1.00mm |
| Shank Height (Decimal Inch) | 0.1535" |
| Shank Height (mm) | 3.90mm |
| Tool Entering Angle ( Degree) | 100 Degree |
| Usable Length (Decimal Inch) | 0.1181" |
| Usable Length (mm) | 3.00mm |
| Corner Radius (Decimal Inch) | 0.002" |
| Corner Radius (mm) | 0.05mm |
| Application | Micro Boring |
| Coating Process | PVD |
| Hand | Right Hand |
| Insert Grade | PR930 |
| Insert Holding Method | Screw |
| Material | Carbide |
| Primary Workpiece Material | Steel (P) |
