Features:
| Tool Number | TLC19857 |
| Max Depth of Cut (Decimal Inch) | 0.1063" |
| Max Depth of Cut (mm) | 2.70mm |
| Cutting Width (Decimal Inch) | 0.0571" |
| Cutting Width (mm) | 1.45mm |
| Cutting Width Minimum (Decimal Inch) | 0.0571" |
| Cutting Width Minimum (mm) | 1.45mm |
| Cutting Width Maximum (Decimal Inch) | 0.0571" |
| Cutting Width Maximum (mm) | 1.45mm |
| Inscribed Circle (Inch) | 3/8" |
| Inscribed Circle (mm) | 9.525mm |
| Corner Radius (Inch) | 0.002" |
| Corner Radius (mm) | 0.05mm |
| Thickness (Inch) | 1/8" |
| Thickness (mm) | 3.18mm |
| Application | External Grooving |
| Coating Process | PVD |
| Cutting Range | Medium Roughing |
| Hand | Left Hand |
| Insert Holding Method | Screw |
| Insert Grade | PR1535 |
| Insert Size | 145 |
| Material | Carbide |
| Number of Cutting Edges | 3 |
| Primary Workpiece Material | Heat-Resistant Alloy (S) |
| Usage Classification | Light Interruption |
