Kyocera Precision Tools TLC58704 | TWFGL180 PR1535 0.1181" Max Cut of Depth x 0.0709" Width x 0.6299" Insert Length PVD Coated Carbide Micro Face Grooving Bar

$83.99 $48.71
(You save $35.28)
Brand:
Kyocera Precision Tools
Toolholder Style:
TWFG
Series:
TWFG;Hand of Holder=Left-Hand"
interval quantity:
5
SKU:
23242828
UPC:
Weight:
0.06 LBS
Minimum Purchase:
5 units
Shipping:
Calculated at Checkout

Features:

  • PVD carbide PR1535 grade twin bars (Horizontal type) provide efficient micro diameter face grooving of steel, stainless steel
  • 6mm Minimum face groove diameter
  • Compatible with STWL, S-STWL sleeves

Product Specifications
EDP NumberTLC58704
Shank Width (Decimal Inch)0.7874"
Max Depth of Cut (Decimal Inch)0.1181"
Max Depth of Cut (mm)3.00mm
Cutting Width (Decimal Inch)0.0709"
Cutting Width (mm)1.80mm
Cutting Width Minimum (Decimal Inch)0.0709"
Cutting Width Minimum (mm)1.80mm
Cutting Width Maximum (Decimal Inch)0.0709"
Cutting Width Maximum (mm)1.80mm
Minimum Face Groove Diameter (Decimal Inch)0.2362''
Minimum Face Groove Diameter (mm)6.00mm
Insert Length (Decimal Inch)0.6299"
Insert Length (mm)16.00mm
Tool Entering Angle ( Degree)95 Degree
Corner Radius (Decimal Inch)0.002"
Thickness (decimal Inch)3/32"
Thickness (mm)2.38mm
ApplicationMicro Face Grooving
Coating ProcessPVD
Grooving TypeFace Grooving
HandLeft Hand
Insert GradePR1535
Insert Holding MethodScrew
MaterialCarbide
Number of Cutting Edges2
Primary Workpiece MaterialStainless Steel (M)
