Kyocera Precision Tools TLM00541 | GC10L200010 PR1725 0.0787" Cutting width x 0.3780" Insert Length PVD Coated Carbide Grooving Insert

SKU: 23245442 Weight: 0.05 LBS Minimum Purchase: 5 unit
UPC:
$44.12 $25.59
(You save $18.53)
Total Price: $25.59
Shipping: Calculated at Checkout

About This Item

Features:

  • Insert for small internal grooving
  • 1 Cutting edge
  • MEGACOAT NANO PLUS PVD technology provides excellent wear resistance for longer tool life and a high-quality surface finish in steel and stainless applications

Product Specifications
Tool NumberTLM00541
Max Depth of Cut (Decimal Inch)0.0866"
Max Depth of Cut (mm)2.20mm
Cutting Width (Decimal Inch)0.0787"
Cutting Width (mm)2.00mm
Cutting Width Minimum (Decimal Inch)0.0787"
Cutting Width Minimum (mm)2.00mm
Cutting Width Maximum (Decimal Inch)0.0787"
Cutting Width Maximum (mm)2.00mm
Insert Length (Decimal Inch)0.3780"
Insert Length (mm)9.60mm
Corner Radius (Inch)0.004"
Corner Radius (mm)0.10mm
Thickness (Inch)0.173"
Thickness (mm)4.40mm
ApplicationInternal Grooving | Small Parts Machining
Coating ProcessPVD
Cutting RangeFinishing Medium
HandLeft Hand
Insert Holding MethodScrew or Clamp
Insert GradePR1725
Insert Size10
MaterialCarbide
Number of Cutting Edges1
Primary Workpiece MaterialSteel (P)
Usage ClassificationLight Interruption
