Features:
| EDP Number | TLN40004 |
| Cutting Width (Decimal Inch) | 0.2756" |
| Cutting Width (mm) | 7.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.2756" |
| Cutting Width Minimum (mm) | 7.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.2756" |
| Cutting Width Maximum (mm) | 7.00mm |
| Insert Length (Decimal Inch) | 0.6063" |
| Insert Length (mm) | 15.40mm |
| Corner Radius (Inch) | 0.059" |
| Corner Radius (mm) | 1.50mm |
| Thickness (Inch) | 5/32" |
| Thickness (mm) | 3.97mm |
| Application | Back Turning |
| Coating Process | PVD |
| Cutting Range | Finishing |
| Hand | Right Hand |
| Insert Grade | PR1705 |
| Insert Holding Method | Screw or Clamp |
| Insert Shape | Irregular |
| Insert Size | 15-4015 |
| Material | Carbide |
| Number of Cutting Edges | 2 |
| Primary Workpiece Material | Free-Cutting Steel (P) |
| Usage Classification | Continuous |
