Features:
- Insert for back turning
- 2 Cutting edges
- Excellent surface finish cermet grade for stable machining
- Application: For milling, grooving, and threading of steel and stainless steel
Product Specifications
| EDP Number | TSB01656 |
| Cutting Width (Decimal Inch) | 0.2756" |
| Cutting Width (mm) | 7.00mm |
| Cutting Width Minimum (Decimal Inch) | 0.2756" |
| Cutting Width Minimum (mm) | 7.00mm |
| Cutting Width Maximum (Decimal Inch) | 0.2756" |
| Cutting Width Maximum (mm) | 7.00mm |
| Insert Length (Decimal Inch) | 0.6063" |
| Insert Length (mm) | 15.40mm |
| Corner Radius (Inch) | 0.059" |
| Corner Radius (mm) | 1.50mm |
| Thickness (Inch) | 5/32" |
| Thickness (mm) | 3.97mm |
| Application | Back Turning |
| Coating Process | Uncoated |
| Cutting Range | Finishing |
| Hand | Right Hand |
| Insert Grade | TC60 |
| Insert Holding Method | Screw or Clamp |
| Insert Shape | Irregular |
| Insert Size | 15-4015 |
| Material | Cermet |
| Number of Cutting Edges | 2 |
| Primary Workpiece Material | Carbon/Alloy Steel (P) |
| Usage Classification | Continuous |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Insert Style:
ABS
Insert Size:
15-4015
Material:
Cermet;Thickness (Inch)=5/32"""
Thickness (Decimal Inch):
0.1563"
Thickness (mm):
3.97mm
Corner Radius (Decimal Inch):
0.0590"
Corner Radius (mm):
1.50mm
Manufacturer's Grade:
TC60
