- Insert for chamfering, countersinking, back chamfering, V-shape slotting
- Chamfered edge with 4 cutting edges
- Tough cermet with improved oxidation resistance and thermal shock resistance
- Application: Turning of steel at high speed
Product Specifications
| EDP Number | TSP00630 |
| Insert Included Angle (Degree) | 90 Degree |
| Inscribed Circle (Inch) | 1/2" |
| [IC] Inscribed Circle (mm) | 12.70mm |
| [RE] Corner Radius (Inch) | 1/64" |
| [RE] Corner Radius (mm) | 0.40mm |
| [S] Thickness (Inch) | 1/8" |
| [S] Thickness (mm) | 3.18mm |
| Application | Back Chamfering | Chamfering | Countersinking | V-Shape Slotting |
| Chipbreaker | TN |
| Coating Process | Uncoated |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Kyocera Precision Tools
Insert Size:
421
Material:
Cermet;Finish/Coating=Uncoated
Inscribed Circle (Decimal Inch):
0.5000"
Inscribed Circle (mm):
12.70mm
Thickness (Decimal Inch):
0.1300"
Thickness (mm):
3.18mm
