Product Specifications
| Manufacturer Part Number | 17762500A |
| Diameter (Inch) | 5/8" |
| Diameter (Decimal Inch) | 0.625" |
| Shank Diameter (Inch) | 5/8" |
| Shank Diameter (Decimal Inch) | 0.625" |
| Overall Length (Decimal Inch) | 3.000" |
| Length of Cut (Inch) | 5/8" |
| Length of Cut (Decimal Inch) | 0.625" |
| Helix Angle (Degree) | 35-38 Degree |
| Number of Flutes | 4 |
| Shank Type | Straight |
| Tool Construction | Solid |
| Coating | ALtima |
| Material | Carbide |
| Center Cutting | Yes |
| Product Type | Square End Mill |
| Country Of Origin | USA |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
M A Ford
Mill Diameter (Inch):
5/8"
Mill Diameter (Decimal Inch):
0.6250"
Length of Cut (Inch):
5/8"
Length of Cut (Decimal Inch):
0.6250"
Shank Diameter (Inch):
5/8"
Shank Diameter (Decimal Inch):
0.6250"
Overall Length (Inch):
3"
Overall Length (Decimal Inch):
3.0000"
Material:
Carbide
Finish/Coating:
ALtima
Single or Double End:
Single
Cutting Direction:
Right Hand
Flute Direction:
Right Hand
Center Cutting:
Yes
Number of Flutes:
4
Ships:
From Partner Facility
interval quantity:
1
