Product Specifications
| Min Bore Diameter (mm) | 4mm |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (mm) | 25mm |
| 0.990mmShank Diameter (mm) | 4mm |
| Centerline Offset (mm) | 2mm |
| Face Dimension (mm) | 0.08mm |
| Neck Diameter (mm) | 3.000mm |
| Overall Length (mm) | 50mm |
| Split Length (mm) | 2.50mm |
| Tooth Width (mm) | 2.160mm |
| Metric (Yes/No) | Yes |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Minimum Bore Diameter (mm):
4mm
Maximum Bore Depth (mm):
25mm
Material:
Carbide
Shank Diameter (mm):
4mm
Overall Length (mm):
50mm
Finish/Coating:
AlTiN
Ships:
From Partner Facility
IsDiscontinued:
