Product Specifications
| Hand Direction | Left Hand |
| Finish/Coating | Uncoated |
| Corner Radius (Inch) | 1/64" |
| Corner Radius (Decimal Inch) | 0.015" |
| Brazed Insert Length (Inch) | 1/2" |
| Brazed Insert Length (Decimal Inch) | 0.500" |
| Brazed Insert Width (Inch) | 1/4" |
| Brazed Insert Width (Decimal Inch) | 0.250" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.50" |
| Shank Height (Inch) | 3/8" |
| Shank Height (Decimal Inch) | 0.3750" |
| Shank Width (Inch) | 3/8" |
| Shank Width (Decimal Inch) | 0.3750" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Tool Bit Style:
BL
Type:
Turning
Cutting Direction:
Left Hand
Shank Width/Diameter (Inch):
3/8"
Shank Width/Diameter (Decimal Inch):
0.3750"
Shank Height (Inch):
3/8"
Shank Height (Decimal Inch):
0.3750"
Overall Length (Inch):
2-1/2"
Overall Length (Decimal Inch):
2.50"
Ships:
From Partner Facility
IsDiscontinued:
