Product Specifications
| Min Bore Diameter (Decimal Inch) | 0.1200" |
| Hand Direction | Right Hand |
| Finish/Coating | AlTiN |
| Max Bore Depth (Decimal Inch) | 0.600" |
| Projection (Decimal Inch) | 0.0300" |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Centerline Offset (Decimal Inch) | 0.0263" |
| Offset (Decimal Inch) | 0.017" |
| Radius (Decimal Inch) | 0.0020" |
| Angle per Side | 30 |
| Face Dimension (Decimal Inch) | 0.094" |
| Neck Diameter (Decimal Inch) | 0.0850" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.00" |
| Split Length (Decimal Inch) | 0.070" |
| Thread Size | 32-56 |
| Tooth Width (Decimal Inch) | 0.0350" |
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Warning:
This product can expose you to materials and/or chemicals including arsenic, lead, and other materials and/or chemicals which are known to the state of California to cause cancer and/or reproductive harm.
For more information, visit www.P65Warnings.ca.gov
Brand:
Micro 100
Material:
Carbide
Tool Bit Style:
IT
Type:
Turning
Cutting Direction:
Right Hand
Shank Width/Diameter (Inch):
3/16"
Shank Width/Diameter (Decimal Inch):
0.1875"
Overall Length (Inch):
2"
Overall Length (Decimal Inch):
2.00"
Minimum Bore Diameter (Decimal Inch):
0.1200"
Maximum Bore Depth (Decimal Inch):
0.600"
Thread Size:
32-56
Finish/Coating:
AlTiN
Ships:
From Partner Facility
IsDiscontinued:
